Temperature Humidity Test Chamber
Boto as a Temperature Humidity Test Chamber supplier. With nearly 30 years of experience in the production of environmental testing equipment, our product lines cover CNC machine tools and fully automatic laser cutting machines. Our technical and service teams have accumulated rich experience over many years. You can learn more about our products. If you have any special needs or questions, please feel free to contact us. We will provide you with professional pre-sales and after-sales services to ensure that your needs are fully met.
What is Temperature And Humidity Test Chamber?
Constant temperature and humidity test chamber is a kind of reliability environmental test equipment. It can simulate the natural temperature and humidity conditions in the real environment. It is used to test the performance of materials in various environments and test the heat resistance, cold resistance, dryness resistance and moisture resistance of various materials to improve product reliability.
What are advantages of Temperature And Humidity Test Chamber?
Easier installation
The equipment is delivered as a complete machine and can be put into use after connecting the power supply and water pipes.
Top quality
All components are from world-renowned brands, which are safe and reliable, have a long life cycle and more accurate data.
High durability
With our advanced design technologies and use of high-grade materials,The body of the equipment is made of high-quality brushed stainless steel, which has beautiful appearance and solid quality.
Ultimate performance
Our constant temperature and humidity test chamber can reach a maximum high and low temperature of -70℃~+180℃, and the humidity can be customized to 10%~98%R.H., which can better and more realistically simulate the real environment.
More options
Our constant temperature and humidity test chambers are available in various models with more flexible content, ranging from 50L to 1000L. Larger ones can also be customized to meet customers' testing needs for various products.
Lower maintenance requirements
The equipment is simple to maintain. Simply performing daily maintenance as much as possible during the test can greatly increase the life cycle of the equipment and make customers more worry-free.
Types of environmental test equipment
Temperature And Humidity Test Chamber
Equipment used to test the performance of materials in various environments and to test the heat resistance, cold resistance, dryness resistance and moisture resistance of various materials.
UV aging test chamber
UV aging test chamber is a kind of equipment used to simulate and test the aging performance of materials in UV environment. It simulates the ultraviolet radiation in the natural environment to perform aging tests on materials to evaluate the weather resistance, corrosion resistance and other related properties of the materials.
Salt spray test chamber
The salt spray test chamber is a device that can simulate salt spray environments such as oceans and industrial areas. It tests the corrosion resistance of automotive parts or complete vehicles in high salinity and high humidity environments by conducting salt spray corrosion tests on them.
Xenon aging test chamber
Xenon lamp aging test chamber is a kind of equipment used to test the light stability and aging resistance of materials and products. It accelerates the aging process of materials by simulating the sunlight and moisture conditions in the natural environment, thereby evaluating the durability and performance of materials.
Rain test chamber
The rain test chamber tests the waterproof performance of products by simulating the water and spray environment that electronic products and their components may be exposed to during transportation and use.
Ozone Aging Test chamber
The ozone aging test chamber is a device that simulates and accelerates the aging process of rubber and plastic materials in an ozone environment. It simulates the environmental factors such as ozone concentration and temperature that the materials are subjected to during actual use to accelerate the aging process of the materials, thereby predicting the performance changes of the materials in the future.
Sand and dust test chamber
The sand and dust test chamber is a device used to simulate the sand and dust environment. By simulating the dust environment of natural dust falling, sand and dust tests can be carried out on various materials and equipment under laboratory conditions.
Specification of Temperature And Humidity Test Chamber
| Model | B-TH-80 (A~G) |
B-TH-150 (A~G) |
B-TH-225 (A~G) |
B-TH-408 (A~G) |
B-TH-608 (A~G) |
B-TH-800 (A~G) |
B-TH-1000 (A~G) |
| Inside size WxHxD (cm) |
40x50×40 | 50x60x50 | 50x75×60 | 80x85x60 | 80x95×80 | 100x100×80 | 100x100x10 0 |
| Outside size WxHxD (cm) |
95x145x105 | 105x175x97 | 115x190x97 | 135x185x120 | 145x185x137 | 145x210x130 | 147x210x140 |
| Temperature range | 0°C~+150°C (A:+25C B:0C C :- 20°C D :- 40°C E :- 50°C F :- 60°C G :- 70°C) |
||||||
| Humidity range | 20%~98%R.H.(10%-98%R.H/5%~98%R.H is the specific condition) | ||||||
Application of Temperature And Humidity Test Chamber
Electronic components industry
Electronic components have very strict requirements on temperature and humidity conditions. The application of constant temperature and humidity test chambers in these industries is mainly reflected in the preservation of electronic components, magnetic media, etc., as well as the production of semiconductors and LCD screens. By simulating various environmental conditions, it ensures that the quality and performance of the product meet the standards.
Hygiene industry (manufacturing of sanitary products)
In the production of products such as paper towels and diapers, important materials such as breathable membranes need to be tested in a constant temperature and humidity test chamber to ensure product quality and performance.
Automotive Industry
As a daily means of transportation, cars will operate under different temperatures, humidity, pressure and altitudes. Constant temperature and humidity test chambers can be used to simulate these environmental conditions to test the performance and reliability of cars.
Various laboratories
Constant temperature and humidity test chambers are used to simulate various environmental conditions for product quality testing and research. For example, in the process of plant cultivation and environmental testing, constant temperature and humidity test chambers play an irreplaceable role.
Textile Industry
The constant temperature and humidity test chamber can be used for heat and moisture loss test of textiles, that is, at a certain temperature and humidity, it simulates the humidity change process of textiles during shuttle motion to test their durability.
How to maintain Temperature And Humidity Test Chamber?
Sample limit
It is prohibited to use this equipment to test samples of flammable, explosive, volatile, and corrosive substances.
Equipment placement
The equipment should be placed in a place with good air circulation and stable airflow, and should not be affected by external factors such as direct sunlight and heat sources to avoid affecting the accuracy of the test.
Use the instrument correctly
Before use, you must first understand the usage and instructions of the equipment and use it correctly according to the requirements of the instructions to avoid misuse that may lead to inaccurate test results.
Pay attention when opening the door
It is strictly forbidden to open the box door at will during the test, as high and low temperature air will affect the personal safety of the tester.
Pay attention to warning tips
During the test, it is necessary to carefully observe the operating status of the equipment and the on and off status of the indicator lights, and deal with abnormal situations in a timely manner to avoid equipment failure or other accidents.
Pay attention to maintenance
It is best to perform regular maintenance after testing to extend the life of the equipment.
Components of Temperature And Humidity Test Chamber
1. Inner and outer chamber
The inner and outer boxes are made of high-quality brushed stainless steel, which is sturdy and durable. The exterior is painted and sprayed with plastic, making the equipment more beautiful.
2. Control System
Controller touch screen, including lighting switch, USB interface (on the control panel); main power switch, over-temperature protection setting device, and communication interface.
3. Cooling system
The compressor can be selected as single-stage (air-cooled) or double-stage refrigeration system (water-cooled). The evaporator adopts a finned heat exchanger and the refrigerant adopts environmentally friendly R404a/R23 with an ozone depletion index of 0.
4. Heating system
The heater adopts nickel-chromium alloy electric heating wire heater;
Heater control method: SSR (solid-state relay) contactless equicyclic pulse width modulation
5. Humidification system
The humidification method adopts electric steam humidification, and the equipment has automatic water replenishment function.
6. Noise reduction system
The low-temperature pipeline is equipped with shock-absorbing process pipes to reduce the noise caused by the operation of the compressor; the refrigeration unit uses shock-absorbing springs or rubber pads for shock absorption and noise reduction; the inner side of the unit enclosure is affixed with sound-absorbing materials for noise reduction.
Process of Temperature And Humidity Test Chamber
Design
After the customer inquires and places a PO, we will immediately set up a project team to start confirming the design plan for the equipment purchased by the customer and confirm the plan details with the customer.
Slicing
Once the plan is finalized, we will start preparing production materials. The first step is to cut the entire piece of stainless steel into modules of different sizes that match the equipment plan.
Bending
After cutting the raw materials, we will use a bending machine to bend the cut materials to prepare for subsequent production.
Laser cutting
Next, laser cutting will be carried out to cut off the excess scraps without affecting the practicality and aesthetics of the equipment.
Welding
The next step is to carry out preliminary welding of the equipment. At this step, the appearance of the equipment is basically completed, and the equipment completes the first stage.
Painting
The welded equipment surface will then be sprayed with plastic, and then cured and dried, at which point the equipment outer chamber is completed.
Wiring
Next is the wiring control inside the equipment, which is a preliminary preparation for the electronic control assembly.
Electric control
The core components inside the assembly equipment are all from internationally renowned brands. This is the key hub of the equipment.
Assembling
The next step is to assemble all the completed parts together, at which point the equipment is finished.
Testing
After production is completed, the equipment will be tested and calibrated before leaving the factory. This step is very strict and must be inspected and qualified by the quality inspection department before the next step of shipment can be carried out.
Cleaning
When the equipment is about to be shipped, it will first be cleaned as a whole to remove some water stains from the trial run.
Package
Finally, our logistics department will pack and ship the equipment. The equipment will use standard export packaging: plywood wooden case packaging to ensure smooth transportation of the equipment.
Compared with traditional Temperature And Humidity Test Chamber , our this product
Cooling system for compressor
A cooling fan is installed above the large compressor cylinder to ensure that the temperature of the compressor will not be too high when it is working, thereby extending the service life of the compressor.
Advanced cooling system
The refrigeration system adopts German technology and has an anti-frost design. It will not frost during long-term operation, which saves energy and reduces consumption. The compressor is equipped with a cooling fan to ensure efficient operation.
Thoughtful details
1. Each solenoid valve has a sign, which can find the problem point in the first time when the component has a problem, and can be maintained;2. The capillary tubes are tied with cable ties and fixed on the main tube to reduce space occupation and make the space more beautiful and tidy;3. All pipelines are protected, small copper tubes are protected by bellows and fixed with cable ties, which can reduce friction and vibration and increase service life;4. The welding points of copper tubes are finely polished and coated with anti-corrosion varnish.
Electrical control system
Most of the components are from international first-line brands. The wiring is neat and standardized, all lines are marked with line numbers, and components are labeled for easy maintenance; filters are installed on inductor accessories, which will not generate harmonic sources for the power grid and will not affect the voltage amplitude.
FAQ
Q: What is the constant temperature and humidity test chamber?
This equipment can simulate high temperature, low temperature, high humidity or low humidity environment to test the performance and reliability of electronic, electrical appliances, food, automobiles, rubber, plastic, metal and other products. It is of great significance to predict and improve product quality and reliability.
Q: What is the working principle of temperature and humidity test chamber？
Q: What is the function of temperature and humidity test chamber?
Q: What is the temperature humidity test?
Q: What are the applicable industries for constant temperature and humidity test chambers?
1. Electronic and electrical industry: used to test the performance and reliability of electronic components, circuit boards, complete machines, etc. under high temperature, low temperature, damp and hot environments.
2. Automobile industry: test the performance of automobile parts, complete vehicles, etc. under extreme climatic conditions, such as engines, batteries, body materials, etc.
3. Plastic and rubber industry: simulate the aging of materials under high temperature and high humidity conditions to evaluate the service life of the product.
4. Aerospace industry: test the performance of aircraft parts under extreme climatic conditions to ensure that they can work normally under various environmental conditions.
5. Scientific research field: provide stable environmental conditions for scientific researchers for material research, biological experiments, etc.
Q: What are the components of a constant temperature and humidity test chamber?
Q: What is the method of temperature humidity chamber test?
The temperature test involves setting the required temperature, humidity and time in the instrument parameters at one time. The test chamber will operate according to the set program to simulate different temperature environments to test the heat resistance of the sample.
The humidity test is based on the temperature test and adds a humidity system, so that the humidity test can be performed while testing the temperature. This test method is closer to natural climate conditions and can simulate a more severe natural environment, so as to more effectively test the weather resistance of the sample.
Q: What is a walk in temperature and humidity chamber?
The walk-in constant temperature and humidity test chamber is mainly used in the product development and testing stage. It simulates high and low temperature or hot and humid environments to test the performance indicators of aerospace products, information electronic instruments, materials, electrical engineering, electronic products and various electronic components.
Q: What should you pay attention to when using the constant temperature and humidity test chamber?
1. Power supply and voltage: Make sure to use it within the specified voltage range to avoid machine failure;
2. Installation and wiring: After installation or work, make sure the power is disconnected. The wiring should be correct and grounded to prevent electric shock;
3. Safe environment: Do not use the constant temperature and humidity machine in a flammable or explosive environment. Keep the ventilation holes of the machine body unobstructed to avoid dust or wire ends from entering;
4. Operation safety: During operation, do not open the door of the test chamber, especially under high or low temperature conditions, to avoid burns or frostbite;
5. Equipment maintenance: It is strictly forbidden to disassemble, process or modify the constant temperature and humidity test chamber without authorization to avoid abnormal operation, electric shock or fire;
6. Temperature and humidity control: When setting temperature and humidity, follow the maximum operating range of the equipment to avoid damage to the equipment or inaccurate test results.
7. Long-term use: During long-term testing, regularly check the water tank and water source in the test chamber to ensure sufficient water supply;
8. Abnormal handling: If any abnormal situation (such as noise, odor, alarm, etc.) is found during operation, the operation should be stopped immediately and the maintenance personnel should be contacted;
9. End of operation: After the operation is completed, turn off the power switch, take out the sample, clean and restore the initial state of the test chamber.
Q: What is the temperature and humidity test chamber ISO standard?
Q: What are the production links of constant temperature and humidity test chamber?
How To Cooperate With Us ?
Send us your specific requirements
Please send us the size and quantity of the products you need to test so that we can recommend the appropriate inner size and temperature and humidity range for you.
Draft design and confirm technical solution
Our professional team will confirm the final plan for you to meet your best expectations.
Production and Manufacturing
After confirming the plan, we can start production for you. You can rest assured that everything will be fine. We can take photos and videos of the production for your inspection.
Packaging and delivery
After production is completed, our logistics department will test the machine for you and ship it to your laboratory as soon as possible for use.
Certifications
We're professional temperature humidity test chamber manufacturers and suppliers in China, specialized in providing various kinds of testing equipments. We warmly welCOme you to buy high quality temperature humidity test chamber from our factory. COntact us for more cheap products.
